C95700 Nickel-Aluminum Bronze
Find below the search results for the material you've specified. Please note here this information is NOT to be used for design purposes, and in no event shall MSO be liable for any damages arising from the misuse of this information.
Product Description
| Bronze Plate & Sheet - Product Specification Table | ||
| Property Category | Specification | Description / Typical Values |
| General Information | Common Names | Bronze Plate, Bronze Sheet, Bronze Shate (Distinguished by thickness) |
| Material Standards | ASTM B103, ASTM B122, ASTM B171, CDA 95400, CDA 95500, CDA 90300 | |
| Material Composition | Primary Alloys | Aluminum Bronze (e.g., C95400), Tin Bronze (e.g., C90300), Nickel-Aluminum Bronze (e.g., C95500) |
| Key Elements | Cu (Copper), Al (Aluminum), Sn (Tin), Ni (Nickel), Fe (Iron) | |
| Physical Properties | Density | Approximately 8.78 - 8.94 g/cm³ (Varies by alloy) |
| Melting Point | ~ 1040 - 1065 °C (1900 - 1950 °F) | |
| Thermal Conductivity | 40 - 80 W/m·K | |
| Mechanical Properties | Tensile Strength | 450 - 960 MPa (65,000 - 140,000 psi) |
| Yield Strength (0.2% Offset) | 170 - 550 MPa (25,000 - 80,000 psi) | |
| Elongation (% in 2") | 12% - 45% | |
| Hardness | 80 - 200+ Brinell (HB) (High-strength aluminum bronzes are hardest) | |
| Key Characteristics | Corrosion Resistance | Exceptional, especially against seawater, acids, and wear. |
| Wear & Galling Resistance | Excellent (A primary reason for selection) | |
| Machinability | Fair to Good (20% - 80% of free-cutting brass) | |
| Non-Sparking | Yes (Critical for tools in explosive environments) | |
| High Strength | Retains strength at elevated temperatures. | |
| Available Forms | Thickness Classification | Sheet: Typically < 3.0 mm (0.125") Plate: Typically > 3.0 mm (0.125") |
| Thickness Range | 0.5 mm - 150 mm (0.020" - 6 inches) and thicker | |
| Width & Length | Standard sheets/plates or cut-to-size. | |
| Temper | Annealed, As-Rolled, Hard | |
| Common Applications | Industrial | Wear Plates, Bushings, Gears, Thrust Bearings, Valve Components |
| Marine & Offshore | Propellers, Hull Fittings, Pump Components, Deck Hardware | |
| Architectural | Decorative Facades, Sculptures, Roofing | |
| Specialized Tools | Non-Sparking Tools for Oil & Gas, Mining, and Chemical Industries | |
